Technical Resource
A useful steel plate price request starts with grade/standard, dimensions, quantity, processing, inspection/documents, destination, Incoterm and required date. Do not publish a generic per-ton selling price: plate quotations are specification- and logistics-dependent, while external HRC benchmarks are only directional market context.
Separate the directional external benchmark from the supplier quotation. Use the quote readiness and cost-driver builder to build a normalized, copyable RFQ from plate type, grade/standard, dimensions, quantity, processing, inspection/documents, destination, Incoterm and required date — never from an invented live price.
Quote readiness scored — no invented live prices published
Information current as of
Quote Readiness & Cost-Driver Builder
Score how complete your RFQ is, explain the price-forming cost drivers that still matter, and copy out a normalized quote-ready specification. This builder never calculates or publishes a live per-ton price.
Plate cost drivers
Plate price is formed by specification and logistics together. The drivers below are exactly what a quotation is built on.
Benchmark = context, never a price
External index data (e.g. CME HRC futures) is directional market context only and must be date/contract labelled. It is neither a Noor Deira Steel price, a GCC spot quote, nor an RFQ substitute — a plate quotation is specification- and logistics-dependent.
Method
Plate pricing is specification- and logistics-dependent. Understand the steps so you compare quotations on a like-for-like basis and can catch a misleading figure.
1 — Fix the specification
The quoted plate starts from the exact standard/edition, grade, dimensions, thickness tolerance and delivery condition. Any of these unknown leaves the figure unbounded.
2 — Add processing & inspection
Cutting, edge, surface and test scope (mill test, third-party, dimensionals) change scope, saw-loss and lead-time. State them before comparing totals.
3 — Normalize the logistics basis
Destination, Incoterm, packing and required date change the landed figure. A per-ton number without these is not a comparable steel-plate offer.
The disciplined check-clear is: set every quotable field
plate RFQ = {
route_type, standard, edition, grade, delivery,
thickness, width, length, unit_system,
weight_basis, edge, surface, cut_to_size,
quantity, destination, incoterm,
inspection, documents, delivery_date
}
total = quote_basis(plate, processing, logistics) // never a static index priceThe external benchmark is directional context only. It is not a Noor Deira price, not a GCC spot quote, and never an RFQ substitute.
Availability, price, origin, lead time and freight are quotation-dependent. Verified against current company data — never invented.
Any supplier figure that "looks right" lacks a basis. Reconcile it against this field set before giving it weight.
Worked examples
Weight is the one plate input you can compute from standard dimensions and density. These worked examples produce plate mass and part-count — never a selling price. A per-ton price is only a quote against a full basis.
A36 workhorse plate
ASTM A36 carbon plate, 10 mm × 2500 × 6000 mm.
10 × 2.5 × 6.0 m × 7850 kg/m³ ≈ 1.18 t per plate.
30 plates ≈ 35.3 t theoretical mass.
Density 7850 kg/m³ is standard for carbon plate; add the tolerance/weight-basis choice at quote.
Pressure-vessel plate
ASTM A516 Gr 70, 6.35 mm × 2000 × 4000 mm.
6.35 mm × 2.0 × 4.0 m × 7850 kg/m³ ≈ 0.40 t per plate.
50 plates ≈ 19.9 t theoretical mass.
A516 testing scope (tensile, bend, optional UT) must be confirmed before a runner is made.
Higher-strength structural
S355JR / ASTM A572 Gr 50, 12 mm × 2500 × 6000 mm.
12 × 2.5 × 6.0 m × 7850 kg/m³ ≈ 1.41 t per plate.
40 plates ≈ 56.5 t theoretical mass.
Higher-strength grades still resolve to the same mass basis — only the grade/standard changes the quote.
No unit price is shown. Send grade, size, quantity and destination to receive a basis for a technical RFQ — see the working tool and the RFQ form.
Standards & inputs
Every plate RFQ must state the size system and tolerance basis before it can be normalized. The inputs below mirror the standard-thickness and dimension references used across the technical library.
Inspection, measurement & tolerance — confirm before quoting
Size & tolerance inputs to state
Verification controls
The discipline that makes a steel plate number trustworthy is the same set of checks a professional buyer applies before relying on any figure.
Fabrication & edge condition — part of the quoted scope
Never publish a generic per-ton price
A plate cost depends on grade/standard, dimensions, quantity, processing, inspection, destination, Incoterm and date. A static figure would be misleading.
Label external benchmarks
Index values (e.g. CME HRC) carry a date and contract definition — treat them as directional context, never as an offer.
Verify before a substitute
An alternative grade is only comparable where yield/tenile, chemistry, tolerance and test basis meet the governing document.
State certificates to the actual plate
Mill test and traceability claims must correspond to the quoted plate and what the specification requires.
Selection handoff
This guide sets the disciplined basis. The decision itself is confirmed against the plate range, size charts, grades and the RFQ desk — not a static price table.
Plate selection starts with the grade/standard and cut-to-size need. Cross-check the plate grade library and size chart, then confirm the RFQ basis with the commercial desk.
Steel plate range
Confirm the plate families and types available for the grade/standard scope.
ASTM A36 plate
The most common structural carbon plate — verify dimensions and tolerance basis.
Steel plate size chart
Cross-check nominal thickness, width and length against the charted range.
Steel prices
Review benchmark and price drivers for directional market context before quoting.
Method & drivers
Separating the specification, processing and logistics drivers in a quote makes the number auditable and the RFQ comparable.
| Cost driver | What it changes in the quote | State in RFQ |
|---|---|---|
| Plate type & route | Which product family and processing route the plate maps to | Route / type |
| Standard, edition & grade | Mechanical & chemical target, tolerance and test scope | Standard + grade |
| Dimensions & unit system | Mass basis and any cut-to-size saw-loss | Thickness × width × length |
| Weight / quantity basis | Theoretical vs. actual weight totals | Basis + quantity |
| Processing & inspection | Scope, certificates, lead time and margins | Edge/surface + tests |
| Destination, Incoterm, packing | Freight and landed figure | Place/port + Incoterm |
| Required documents & date | Docs set and schedule pressure | Documents + timing |
No singular driver sets a plate price — the whole field set above does. A figure quoted against only part of it is not a comparable steel-plate offer.
Worked examples
Each row computes plate mass from declared dimensions and density — the only part of a quote that is fixed arithmetic. The commercial figure is left to the RFQ desk.
| Grade / standard | Dims (mm) | Mass / plate | Pcs × mass |
|---|---|---|---|
| ASTM A36 | 10 × 2500 × 6000 | ≈ 1.18 t | 30 → ≈ 35.3 t |
| ASTM A516 Gr 70 | 6.35 × 2000 × 4000 | ≈ 0.40 t | 50 → ≈ 19.9 t |
| S355JR / A572 Gr 50 | 12 × 2500 × 6000 | ≈ 1.41 t | 40 → ≈ 56.5 t |
Mass is arithmetic; price is not. Confirm grade, dimensions, quantity and destination, then request the commercial basis from the RFQ desk.
Related ranges
Confirm the plate grade and cross-check adjacent ranges that share the same quote-readiness discipline.
Steel Plate
Carbon, alloy, shipbuilding and abrasion plate families.
Steel Sheet
Thinner flat-rolled product for sheet applications.
Steel Coil
HR / CR / GI / PPGI coil, the flat-rolled upstream.
If you are comparing flat-rolled products (plate vs. sheet vs. coil), the size chart and price benchmark cross-link provide the directional basis — no static per-ton price.
RFQ reference
Send these fields to the commercial desk for a technical RFQ. No pre-filled stock, price, origin, mill, lead-time or certification claim is assumed.
| RFQ field | Example / notes |
|---|---|
| Plate type / route | Carbon, pressure-vessel, boiler, shipbuilding, abrasion, alloy or stainless |
| Governing standard & edition | e.g. ASTM A36, A516 – 22, EN 10025 S355 |
| Grade / designation | e.g. Gr 50, S355JR |
| Dimensions & unit system | Thickness × width × length in mm or inch |
| Weight / quantity basis | Theoretical vs. actual; part count or tonnes |
| Processing & edge condition | Mill edge, shear, cut-to-size, surface |
| Inspection / testing | Mill test, third-party, dimensionals, UT |
| Required documents | MTC, CoA, traceability, marking |
| Destination & Incoterm | Named place/port, FOB / CIF / EXW / DAP |
| Required delivery timing | Q4 2026, within 30 days |
For professional buyers
The same field set that prices plate reliably also makes procurement decisions auditable.
Comparable
Quotations normalized on the same fields — total versus total, not apples to oranges.
Auditable
Every figure resolves to a declared specification, logistics and document basis.
No invented numbers
Mass is arithmetic; price is a basis. No fake totals or discounts are published.
Faster to close
Handing over a complete field set cuts the back-and-forth before the commercial desk.
From enquiry to delivery
A disciplined path from this guide to a normalized, commercial basis and a confirmed plate decision.
Define the spec
Grade/standard, edition, dimensions, tolerance and delivery condition.
Add processing & scope
Edge/surface, cut-to-size, inspection/testing and documents.
Normalize logistics
Destination, Incoterm, packing and required timing.
Request the basis
Send the full RFQ — the desk confirms a like-for-like commercial figure.
Buyer FAQ
Concise, factual answers for procurement teams preparing a plate RFQ.
State the governing standard and edition, the exact grade (for example ASTM A36 or ASTM A516 Gr 70, or an EN designation such as S355JR), the delivery condition, and any supplementary requirements — for example notch-toughness, ultrasonic inspection, or edge condition. Each changes the tolerance and testing scope a quotation relies on.
Confirm nominal thickness, width and length (with the unit system), the ordered tolerance basis (theoretical vs. actual weight), edge and surface condition, any cut-to-size or machining requirement, and a consistent quantity basis — for example weight, or number of plates at a fixed size.
State the inspection basis, the test certificates required (mill test certificate, analysis certificate, any third-party inspection), and the traceability or marking requirements. Certificates must align to the actual quoted plate — request only what the governing specification requires.
An alternative plate grade or standard is comparable only when its mechanical properties, chemistry, thickness tolerance and test basis meet the design requirement. Verify yield/tenile strength, chemistry and the exact edition against the governing document before accepting any substitution — never assume equivalence.
Destination country and named place or port, Incoterm, packing and handling requirements, export documentation, and required delivery timing all change the commercial offer. Each must be stated so the quotation is compared on a normalized, like-for-like basis.
Send a technical RFQ
Send grade, size, quantity and destination for technical RFQ support. List only what you know — no stock, price, origin, mill, lead-time or certification claim is pre-filled.
All RFQ fields are lead/contact data only — never payment, login or account details.
Related registered tools & routes
Verified technical routes that share the plate price-guide discipline.
GCC supply
The same quote-readiness discipline applies to every destination market — plate is supplied into projects and fabricators across the region.
United Arab Emirates
Specification & door delivery
UAE plate procurement is coordinated from Dubai — grade/standard, dimensions, tolerance basis, processing, quantity, inspection/documents, destination and Incoterm are reconciled with the fabricator before a quotation is formed.
Saudi Arabia
Project-grade volumes
Saudi fabrication and giga-project supply runs on exact grade/standard and dimensions — tolerance basis, test certificate set and Incoterm are aligned to project hold points before quoting.
Qatar
Submittal approval
Qatar infrastructure and EPC supply prioritises technical submittal approval — thickness, grade/standard and document set are agreed before a quotation basis is fixed.
Kuwait
Fabricator cutting hand-off
Kuwait contractor and oil-sector supply links plate choice to the cut-to-size requirement — dimensions, unit system and edge/processing condition are fixed early in the scope before comparing quotes.
Bahrain
Marine & industrial plate
Bahrain shipbuilding and industrial plate supply depends on accurate documentation — grade/standard, inspection/testing and the certificate set are coordinated to the delivery.
Oman
Port-oriented supply
Oman projects route through port destinations — dimensions, weight/quantity basis and destination-preparation inputs are harmonised to the fabrication or end-use application.
Destination and Incoterm are reconciled per country at quotation — send grade, size, quantity and destination for a destination-ready technical RFQ basis.
Expert insight
External index data is directional reference only. This is how a professional reader uses it without mistaking it for a plate offer.
Directional context, never a price
An index such as HRC futures is a dated, contract-defined reference for flat-rolled market direction. It is not a Noor Deira Steel price, not a GCC spot quote, and never a substitute for an RFQ — plate price is specification- and logistics-dependent.
Use it to gauge broad market mood, then drop into the quote-readiness builder and the RFQ desk for a basis that actually applies to your plate.
Primary source of record
CME Group — U.S. Midwest Domestic Hot-Rolled Coil Steel (CRU) Index FuturesInformation current as of
External index read as directional benchmark context only — verify against the governing specification before relying on any per-ton figure.
